Terminal Block Board for FireBeetle 2 ESP32-E IoT Microcontroller

Description:

The Terminal Block Board for FireBeetle 2 ESP32-E IoT Microcontroller is an expansion shield that converts the mainboard's pins into screw terminal blocks for secure, reliable wiring, making it ideal for permanent installations and projects requiring stable connections. It is specifically designed for the FireBeetle 2 ESP32-E IoT Microcontroller (which supports Wi-Fi and Bluetooth).

Features:

Terminal block, more stable and reliable connections
All pins of the mainboard are broken out
External Voltage Input: 7-24V
GDI for connecting the display
Clear colorful silkscreen
Terminal block status indicator
Terminal block status indicator switch

Applications:

Smart Soil conditioner
Multiple Relays Project

Documents:

• Product wiki
• CAD
• 3D-Model
• Dimension
• Schematics
• SchDoc

Specifications:

External Voltage Input: 7-24V
Screen Port: GDI
5V Port x3
3.3V Port x3
GND Port x6
Digital Port x12
Analog Port x5
I2C x3
SPI x1
Port Indicator x34
Port Indicator Color: blue, red
Default ON Port Indicator: 5V, 3.3V, D0, D1, D5, D6, A4, RST
