Description
The MC Board, installed in the printer's electronics section, governs precise movements and control over the printer's operation.
Features
Triple-Core Processing: Utilizes Cortex-M7 and dual Cortex-M4 processors to handle motion planning and sensor feedback loops in parallel.
PMSM Servo Coordination: Provides the high-frequency control signals needed for the closed-loop extruder motors, enabling active jam detection and flow compensation.
Enhanced Heat Dissipation: Mounted on a custom aluminum heatsink plate to ensure stable operation even when the internal electronic bay reaches elevated temperatures.
Precision Timing: Governs the "Pick and Place" timing of the hotend rack with micron-level step accuracy to ensure reliable tool changes.
In the Box
H2 Series
P2S
-
MC Board*1
-
BT2x5 Screws*3
-
M2x5 Screws*2
-
PW2.2x4.8x0.3 Washers*2
-
Thermal Grease (5g)*2
X2D
- MC Board *1
- BT2x5 Screw *3
Compatibility
H2 Series, P2S, X2D
Specifications
H2 Series
Materials: Circuit board
Color: Black
Packaging Weight: 0.169 kg
Packaging Size: 180*165*35 mm
P2S
Materials: PCBA
Color: Grey, Black
Packaging Weight: 0.057Kg
Packaging Size: 100*135*45mm
X2D
Materials: Copper
Color: Black
Packaging Size: 137*103*48mm
Packaging Weight: 0.073KG
