SKU:MLE08584

Arduino UNO Q 2GB

₱3,990.00
₱3,990.00
Sale Sold out
Tax included. Shipping calculated at checkout.

Loading locations...
Product Description

Description:

Arduino UNO Q bridges high-performance computing with real-time control, supporting advanced applications such as object recognition, voice commands, motion detection, and more. Get power and ease of use – all wrapped up into UNO. This 2-GB variant is a cost-effective choice if you plan to code while connected to a computer and create a project that does not require a monitor or keyboard to run.


This variant of Arduino UNO Q features 2 GB of RAM and 16 GB of eMMC, making it the best choice if:
  • You intend to develop code for UNO Q in the familiar, PC-connected mode, and your project basically requires running the OS, Python scripts, and basic network services accessed remotely (SSH) – no demanding GUI.
  • You plan on the microprocessor running one primary application, without heavy multitasking.
  • Your project leverages no AI or lightweight Edge AI, relying on memory-optimized TinyML applications.
  • You just need local storage for basic OS and core libraries.



Arduino UNO Q is the go-to tool to prototype your next robotics or IoT project:
  • All-in-one toolbox: Arduino UNO Q combines the powerful Qualcomm® Dragonwing™ QRB2210 microprocessor (MPU) with a real-time STM32U585 microcontroller (MCU) – no matter what you’re building, it’s your new go-to tool!
  • AI in a blink: unlock AI-powered vision and sound solutions that react to their environment.
  • Arduino support and developer tools including libraries, sketches, and projects developed for the UNO ecosystem by millions of users.
  • Compatible with the Arduino UNO ecosystem: UNO Q works with a wide range of Arduino hardware, from classic UNO shields to new carriers, and includes a Qwiic connector for Modulino® nodes and third-party modules.
  • Streamlined software experience: in addition to Arduino IDE and Arduino Cloud, you can jumpstart development with plenty of pre-built examples and AI models available through Arduino App Lab.
  • Seamless, unified development: build classic Arduino Sketches, code in Python® thanks to the pre-installed Linux® Debian OS, or mix the two from a single interface – it’s easy, with Arduino App Lab.



Specifications:

Cloud Compatible: Yes
Family: UNO
Series: Arduino Maker
Logic level voltage: 3.3V
Digital I/O Pins: 47
Analog Input Channels: 6
PWM Channels: 6
DC Current per I/O Pin: 20mA
Microprocessor (MPU): Qualcomm Dragonwing™ QRB2210:
Quad-core Arm® Cortex®-A53 @ 2.0 GHz
Adreno GPU 3D graphics accelerator
2x ISP (13 MP + 13 MP or 25 MP) @ 30 fps
Microcontroller (MCU): STM32U585
Arm® Cortex®-M33 up to 160 MHz
2 MB flash memory
786 KB SRAM
RAM: 2GB LPDDR4
Power Supply: From USB-C connector 5 V max at 3 A
Input Voltage (VIN): 7-24 V
Storage: 16GB eMMC
USB: 1× USB-C port with host/device role switching, power role switch and video output
Connectivity: Wi-Fi® 5 2.4/5GHz with onboard antenna
Bluetooth® 5.1 with onboard antenna
Interfaces:
I2C/I3C
SPI
PWM
CAN
UART
PSSI
GPIO
JTAG
ADC
Video: Video output support via USB-C
MIPI DSI pins on JMEDIA header
Extra: 4× RGB user-controllable LEDs
8x13 Blue LED Matrix
1x Qwiic connector voltage 3V3, I2C
1x User push-button
JCTL: MPU Remote Debug connector
Audio: Microphone IN / Headphone OUT / Line OUT on JMISC
Dimensions: 68.85 mm x 53.34 mm (UNO form factor)
MPU Operating System: Linux Debian OS with upstream support
Real-time Operating System: Arduino Core on Zephyr OS
Containerization: Docker and Docker Compose support
Support Operating Systems for Arduino App Lab: Windows: Windows 10 or later (64-bit)
macOS: macOS 11 or later (64-bit)
Linux: Ubuntu 22.04 or later, and Debian Trixie (64-bit)
Weight: 0.03 kg



Pinout Diagram:



Documentation:





View Product Details
